| 设计压力 | 1．0MPa |
| 水压试验压力 | 1．25 MPa |
| 设计温度 | 80℃ |
| 腐蚀裕度 | 1mm |
| 分离效率 | 99% |
| 材料 | Q235-B |
| 型号 | 处理量m3/min | 外形尺寸mm | 进出气口DN | 排污口尺寸 | 重量kg | 配套后冷却器型号 | |||
| E | F | G | H | ||||||
| QF6/1 | 6 | 220 | 400 | 133 | 190 | G1" | G1/4" | 12 | HL4/1 ,HL2/1 |
| QF20/1 | 18 | 400 | 600 | 159 | 220 | G1" | G1/4" | 17 | HL5/1,6/1, |
| 18 | 400 | 600 | 159 | 250 | G2" | G1/4" | 19 | HL10/1 | |
| QF40/1 | 42 | 510 | 760 | 219 | 480 | 80 | G1/2" | 59 | HL13/1,20/1 |
| QF60/1 | 60 | 580 | 850 | 273 | 560 | 80 | G1/2" | 98 | HL30/1 |
| 60 | 580 | 850 | 273 | 560 | 100 | G1/2" | 102 | HL40/1 | |
| 60 | 580 | 850 | 273 | 560 | 125 | G1/2" | 108 | HL60/1,70/1,80/1 | |
| QF120/1 | 120 | 580 | 990 | 410 | 700 | 125 | G1/2" | 148 | HL100/1 |
| QF150/1 | 150 | 630 | 1040 | 410 | 700 | 200 | G1/2" | 165 | HL150/1 |
| QF200/1 | 200 | 770 | 1180 | 410 | 700 | 250 | G1/2" | 202 | HL200/1 |
| QF300/1 | 300 | 950 | 1450 | 462 | 760 | 250 | G1/2" | 251 | HL280/1 |
| QF400/1 | 400 | 1400 | 1950 | 612 | 900 | 300 | G1/2" | 387 | HL370/1 |
